Inside each low-profile, tour-grade wood enclosure are a range of unique new features that set ETX apart, combining intelligent technology and innovative industrial design for spectacular results across all applications. EV-engineered high-efficiency transducers and high-powered Class-D amplifiers, Signal Synchronized Transducers (SST) waveguide design and smart FIR-Drive DSP all work together to provide peerless EV sound quality and precise coverage at the highest SPLs
|
Frequency Range |
40 Hz – 20 kHz |
|
Maximum SPL |
135 dB peak dB |
|
Power Consumption |
100 – 240 V~, 50 – 60 Hz, 1.6 – 0.8 A |
|
Power Rating |
2000 W |
|
Frequency Response |
48 Hz – 20 kHz |
|
Coverage (Nominal -6 dB) H |
90 ° |
|
Coverage (Nominal -6 dB) V |
60 ° |
|
LF Transducer |
SMX2150 380 mm (15 in) |
|
HF Transducer |
DH3-B 1.25-in titanium compression driver |
|
Crossover Frequency |
1500 Hz |
|
Connector Type |
(2) XLR/TRS combo jack and (1) XLR link output |
|
Enclosure Material |
18-mm, 13-ply birch plywood with EVCoat |
|
Grill |
16AWG steel with powdercoat |
|
Suspension |
(8) M10 suspension points |
|
Height |
691 mm (27.2") |
|
Width |
431 mm (16.97") |
|
Depth |
447 mm (17.6") |
|
Weight Net |
27.7 kg (61.07 lbs) |
|
Shipping Weight |
31.5 kg (69.45 lbs) |
