Frequency Response 85 Hz – 20 kHz1
Frequency Range 65 Hz – 20 kHz1
Maximum SPL 134 dB peak3
Coverage (H x V) 90° x 60°
Power Rating 2000 W
LF Transducer SMX2100 254 mm (10 in)
HF Transducer DH3‑B 1.25 in titanium compression driver
Crossover Frequency 1700 Hz
Connectors (2) XLR/TRS combo jack and (1) XLR link output
Enclosure 18‑mm, 13‑ply birch plywood with EVCoat
Grille 16AWG steel with powdercoat
Suspension (8) M10 suspension points
Dimensions (H x W x D) 21 in x 13 in x 14 in
(526 mm x 330 mm x 365 mm) 24 in x 15 in x 16 in
(613 mm x 381 mm x 400 mm) 27 in x 17 in x 18 in
(691 mm x 431 mm x 447 mm) 40 in x 18 in x 17 in
(1023 mm x 469 mm x 426 mm) 19 in x 23 in x 32 in
(471 mm x 576 mm x 825 mm)
Without casters:
19 in x 23 in x 27 in
(471 mm x 576 mm x 692 mm) 22 in x 27 in x 36 in
(550 mm x 675 mm x 910 mm)
Without casters:
22 in x 27 in x 31 in
(550 mm x 675 mm x 777 mm)
Net Weight 44.8 lb (20.3 kg) 52.0 lb (23.6 kg) 61.1 lb (27.7 kg) 84.2 lb (38.2 kg) 91.9 lb (41.7 kg) 114.2 lb (51.8 kg)
Shipping Weight 50.5 lb (22.9 kg) 59.1 lb (26.8 kg) 69.5 lb (31.5 kg) 94.4 lb (42.8 kg) 103.2 lb (46.8 kg) 129.9 lb (58.9 kg)
Power Consumption 100 ‑ 240 V~, 50 ‑ 60 Hz, 1.6 ‑ 0.8 A4
