Sensitivity (SPL 1 W/1 m) |
87 dB |
|
Max Calculated SPL |
107 dB Avg, 113 dB Peak |
|
Impedance |
10 ohms |
|
LF Transducer |
165 mm (6.5 in) |
|
HF Transducer |
35 mm Compression Driver |
|
Transformer Taps |
70V: 60W, 30W, 15W, 7.5W, 8 ohm
100V: 60W, 30W, 15W, 8 ohm |
|
Connectors |
Removable locking 4-pin (Phoenix)
2.5 mm (12 AWG) max wire size |
|
Enclosure |
ABS Plastic (UL94V-O) Baffle, steel
back can |
|
Grille |
Color matched steel grille with
fabric |
|
Dimensions (H x Dia) |
260 mm x 280 mm (10.2 in x 11.0
in) |
|
Cutout Size |
248 mm (9.76 in) |
|
Net Weight |
7.0 kg (15.4 lb) |
Shipping Weight
(pair) |
16.83 kg (37.1 lb) |
|
Support Hardware |
C Ring, Tile Bridge |
