The 10W powered speaker is equipped with two 130mm full-range loudspeakers and a 100V line transformer with 4 power adjustments. A robust powder coated aluminum housing in RAL 9010, and a vandal-resistant feet ensure a permanent installation of this speaker. For additional reliability, a 2 pin-ceramic block and a thermal fuse is provided and the speaker chassis is impregnated against wetness.
The speaker is also secured with the high protection class IP 65 against the risks of environmental influences.
Perfectly suitable for the installation in corridors and hallways. The speaker is compliant with the British Standard BS 5839, Part 8.
Special paint of the speaker in 4-digit RAL- or NCS-colour available at extra cost.
|
Artikel Nr.
|
20122650
|
|
Produkt
|
DA 10-260/T-EN54
|
|
Power
|
10/6/3/1,5 W
|
|
Impedance (100V)
|
1000/1667/3333/6667 ohm
|
|
Frequency Range
|
237 - 12.400 Hz
|
|
Frequency Response
|
79 - 17.500 Hz
|
|
SPL 1W/1m, peak
|
95,3 dB
|
|
SPL , 1W/4m, peak
|
83,3 dB
|
|
SPL Pmax/4m, peak
|
93,3 dB
|
|
Sensitivity EN54-24, 1W/4m
|
77 dB
|
|
Sensitivity EN54-24, 1W/1m
|
89,6 dB
|
|
Dispersion -6dB, 500Hz
|
h/v 2x130°
|
|
Dispersion -6dB, 1KHz
|
h/v 2x150°
|
|
Dispersion -6dB, 2KHz
|
h/v 2x145°
|
|
Dispersion -6dB, 4KHz
|
h/v 2x75°
|
|
Connector
|
2-pin ceramic block
|
|
Maximum cable cross section
|
8mm²
|
|
Max. cable cross section loop
|
2x2mm²
|
|
Temperature range
|
-25 / +70 C°
|
|
Dimensions
|
201x176x160 mm
|
|
Type A/B
|
B
|
|
IP Rating
|
IP65
|
|
Weight (net)
|
2,35 kg
|
|
Colour
|
RAL 9010
|
|
Mounting
|
screws
|
|
Packing Unit
|
8
|
|
Ref. Nr.
|
003-14
|
|
ID-Code
|
SAA-LS14
|
|
Certificate Number
|
1438-CPR-0234
|
