Basic Functions:
♦ In compliance with IEC60914 international standard.
♦ The design of physical buttons / knobs is reasonable , which is easy to operate; The buttons / knobs are sensitive with good touch, accurate operation response, long service life and without mechanical button sound.
♦ With fully digital audio technology, built-in high-speed CPU.
♦ Interpreter console, conference terminal, power HUB and conference server are all connected by network cables. Flexible cabling reduces project workload and makes large-scale construction projects easier.
♦ It supports hand-in-hand connection, star connection and mixed connection. The system is highly stable and reliable. The breakdown of one terminal won’t influence the other terminals , and the malfunction of one terminal cabling will not affect the whole system, ensuring the system stability.
♦ Automatic restoration function: supports hot plug.
♦ Supports 48KHz audio sampling freq, acoustic frequency response can be up to 20Hz to 20KHz.
♦ Built-in high-performance digital audio processor( DSP), helpful to remove the useless low frequency and avoid low-frequency acoustical shock, which is better to improve the clarity of sound.
♦ Support 32 channels simultaneous interpretation(including the floor channel).
♦ Support direct interpretation and relay interpretation.
♦ 7-inch TFT LCD screen to display setting information ,input and output channel information.
♦ With channel selection button, long press to quickly increase / decrease the channel, short press to increase / decrease the channel, convenient to select channels.
♦ 7 input channels can be preset, with corresponding shortcut keys and input channel occupation indicator.
♦ 3 output channels can be preset , with corresponding shortcut keys. When all interpreter consoles are closed, the output channel can be automatically switched to the floor channel.
♦ Standard cardioid directional electret microphone with indicator ring (On or Off) . Multiple soft gooseneck microphone stems can be selected (standard: 410mm, optional:310mm/510mm).
♦ Pluggable microphone stem; During the meeting recess, it can be disassembled for equipment maintenance.
♦ Built-in 2W loudspeaker with volume switch; Can play the floor channel or interpreted channel language.
♦ With the same channel interlock function, when the output channel is preset, the occupied channel will skip automatically. Channel output can be set to interlock mode and free mode.
♦ The number of interpreter console in the same room is not limited.
♦ Through software setting, multiple interpreter consoles can be set up in a single language channel. When the interpreter console in the same language channel turns on the microphone, the microphone of the previous interpreter terminal will be automatically turned off.
♦ MUTE key to enable a brief muting of the microphone for cough cut.
♦ Speaking Speed remind function, the interpreter can press the “slow” key to remind the speaker to slow down the speaking speed (The microphone’s indicator ring or screen will flash).
♦ Left and right headphone output jack (3.5 mm×2), connect the headset to listen to the floor or interpreted channel language, with left and right selection buttons; headphone volume is adjustable.
♦ Left and right microphone input jack (3.5 mm×2), can be connected to external microphone, with left and right selection buttons, to meet different usage scenarios.
♦ Left and right recording output jack (3.5 mm×2), can be connected to recording device, with left and right selection buttons, the output audio depends on the channel listened by the interpreter console.
♦ With message function, text message can be sent to interpreter terminal through management software.
♦ With call service function, interpreters can call the administrator to provide help through the interpreter console.
♦ Setting the interpreter console information can be locked by password, and the interpreter can use the setting function through password and IC card.
♦ No need independent system connection, it can be mixed connected with all conference terminals.
♦ Highly resistant to mobile phone interference.
♦ Every interpreter comes with an unique serial number and the conference system supports automatically or manually assigning ID to the corresponding equipment.
♦ Interpretation timing function (timing unit: hour/minute).
Technical Specifications:
Installation Way: Desktop
Connection Way: Network Cable
Display Specifications: 7-inch TFT color display
Frequency Range: 20Hz~20KHz
Sensitivity: -46 dBV/Pa
Equivalent Noise Level: 20dBA(SPL)
Max. SPL: 125dB(THD<3%)
THD: <0.05%
SNR: ≥96dB
Microphone Type: Cardioid directional electret
Directivity: 0°/180°: >20 dB (1 kHz)
MIC Stem Length: 410mm (standard); 310mm/510mm (optional)
Input Impedance: 2KΩ
Headphone Output Jack: 3.5 mm jack×2
Microphone Input Jack: 3.5 mm jack×2
Headphone Load: >16Ω
Headphone Volume: 10mW
Built-in Loudspeaker: 2W/8Ω
Channel Number: 32 channel (including the floor channel)
Power supply: 24V
Max. Power Consumption: 7W
Working Temperature: 0~45℃
Storage Temperature: -20~50℃
