Basic Functions:
◆ Confirm to IEC 60914 international standard.
◆ With full digital audio technology, built-in high-speed CPU and high-performance DSP digital audio processor.
◆ Black tempered glass panel design, simple and high-end design. All the function divisions are clearly layout and easy to operate.
◆ Three routes 8-pin ports to connect conferenc units, another two route 8-pin port for system cascading.
◆ Three routes 13-pin ports to connect conferenc units, another two route 13-pin port for system cascading.
◆ Automatic restoration function: support hot plug and play.
◆ One central control unit is able to accommodate 60-70 units. By cascading extension units, the system can support upto 4096 conference units.
◆ Universal voltage power switch for wider usable range and sufficient power supply.
Technical Specifications:
Max System Capacity: 4096
Standard Capacity: 60~70(different from various models)
Power: AC100~240V, 50/60Hz
MAX Power: 300W
Terminal Connection Port: 8-pin ×5, 13-pin×5
Operating Temperature: 0~45℃
Storage Temperature: -20~50℃
Dimensions (L*W*H): 485mm×350mm×90mm
Installation: Desktop or 19" rack mounting
Weight: 7.6Kg
