Veoma visoka osetljivost, 105 dB 1 V/1 m (139 dB Peak SPL)
Lak sistem montaže, SuperSAM
Za sve vremenske uslove IEC 529 IP 44 & Mil Spec 810 Ekološke specifikacije
Dostupan unutrašnji transformator od 600 V (Sk600PIKS)
EN54-24 Sertifikat tipa B 1438-CPD-0300
Vodootporno povezivanje pomoću SJO kabla
SPECIFICATIONS:
Frequency Range (-10 dB) - 70 - 16000kHz
Weatherized - Yes
Flying - Yes
Minimum Impedance 3.5Ω
Nominal Impedance (Passive) 4Ω
HF Transducer 2-inch DH2T
Speaker Type - Full-Range, Two-Way
MF Transducer - ND12A
Max. SPL/1m (calc)² - 139dB
Coverage (Nominal -6 dB) H 65°
Coverage (Nominal -6 dB) V 65°
LF Transducer One 12-inch DL12BFH (LF), one 12-inch ND12 (MB)
Power Rating - 2400W
System Power Handling (Continuous/Program/Peak) - 600//2400Watts (Const.-dir. horn)
Crossover Frequency - 1800Hz
Enclosure Material - High Density Polymer
Available Color - Black
Sensitivity 1 W/1 m - 105dB
Height - 45.79" (1163mm)
Recommended High-Pass Frequency 90 @Q=1.6Hz
Width - 16.89" (429mm)
Internal Crossover - Yes
Depth - 12.28" (312mm)
Weight Net - 80.03lbs (36.3kg)
Family - Sx
Axial Sensitivity (SPL, 1 W @ 1 m) - 105dB
Passive Power Handling - 2400W peak
Input Connections - SJO cable/gland nut
Directivity Index - 11.3dB
Chassis Size - 304.8 mm
