Coverage (Nominal -6 dB) |
Omnidirectional in normal operating range |
|
Environmental Specs |
Standard versions: IEC 60529 IP44. PI and FG versions: IEC 60529 IP55 |
|
Input Connections |
Phoenix/Euroblock style screw terminals |
|
Internal Passive Low-Pass Filter |
100 Hz 12 dB per octave |
|
Frequency Response (-3 dB) |
70 - 98 Hz |
|
Frequency Response (-10 dB) |
48 - 120 Hz |
|
Recommended High-Pass Frequency |
50 Hz |
|
Sensitivity 1 W/1 m |
99 dB |
|
Max. SPL/1m (calc) |
131 dB |
|
System Power Handling (Continuous/Program/Peak) |
400, 800, 1600 Watts |
|
LF Transducer |
EVS12SB, 12 in (305mm) Driver |
|
Nominal Impedance (Passive) |
Passive: 4, Biamp: 8 Ω |
|
Minimum Impedance |
Passive: 3.4, Biamp: 5.5 Ω |
|
Enclosure Material |
13 Ply Weather Resistant Birch |
|
Grill |
Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind. PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind |
|
Suspension |
(22) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included) |
|
Height |
768.6 mm (30.26") |
|
Width |
406 mm (15.98") |
|
Depth |
413.3 mm (16.27") |
|
Weight Net |
26.2 kg (57.76 lbs) |
