Chassis Size |
203.2 mm (8") |
|
Color |
Black, White |
|
Environmental Specs |
IEC 529 IP24, MIL STD 810 |
|
Input Connections |
2 Neutrik® NL8 |
|
LF2 Power Handling |
200 W continuous, 800 W peak 100-750 Hz |
|
Peak SPL @ 10m |
130 dB 4 Box Array @ 10 Meters |
|
Speaker Type |
Line Arrays |
|
Frequency Response (-3 dB) |
65 – 16,200 Hz |
|
Frequency Response (-10 dB) |
56 - 16,700 Hz |
|
Internal Crossover |
Yes |
|
Recommended High-Pass Frequency |
100 Hz |
|
Sensitivity 1 W/1 m |
99/113 dB Single Box @ 1 Meter |
|
Max. SPL/1m (calc) |
128/138 dB Single Box @ 1 Meter |
|
Coverage (Nominal -6 dB) H |
90 ° |
|
LF Transducer |
1 x 8-in DVN2080 |
|
LF Power Handling |
200 W continuous, 800 W peak Watts 750-1750 Hz |
|
HF Power Handling |
80 W continuous, 320 W peak Watts 1500-6500 Hz |
|
LF Nominal Impedance |
16 Ω |
|
MF Transducer |
1 x 8-in DVN2080 |
|
HF Transducer |
2 x 2-in ND2S |
|
HF Nominal Impedance |
16 Ω |
|
Nominal Impedance (Passive) |
16 Ω |
|
Connector Type |
2 Neutrik® NL8 |
|
Enclosure Material |
EVCoat®-coated birch plywood |
|
Flying |
Included |
|
Grill |
Powder-coated steel |
|
Height |
251 mm (9.88") |
|
Width |
726 mm (28.58") |
|
Depth |
369 mm (14.53") |
|
Weight Net |
21.8 kg (48.06 lbs) |
