TS 200
Color: Black (RAL 9005, jet black)
Cabinet: Full-range
Configuration: Passive 2-Way
Nominal impedance: 8 Ω
Rated power RMS: 300 W
Program power: 600 W
Peak power: 1200 W
SPL 1W/1m: 97 dB
Max. SPL at 1 m (calculated with peak power): 128 dB
Frequency range (-10 dB): 90–20000 Hz
Nominal coverage angle: 90° x 40°
X-Over frequency: 2200 Hz
Voice coil tracking protection: Halogen
Component HIGH: Electro-Voice DH-3
Component LOW: 2 x DND 6130-16
Connector: 2 x NEUTRIK speakon NL4, contacts full-range 1+, 1-, contacts wired through 1+, 1-
Product dimensions (Width x Height x Depth): 199 x 513.5 x 239.5 mm
Net weight: 10 kg
Enclosure material: Aluminum
Grille: Steel
Suspension: 8 x M6
Dynacord Sub 112
Color: Black
Cabinet: Powered 3-Channel Subwoofer
Lo Amplifier Power RMS: 800 W / 4 Ohms
Mid-High Amplifier Power RMS: 2 x 250 W / 4 Ohms
SPL 2,83V/1m (1W/8 ohms): 92 dB
Max. SPL 1m (calc. with peak power or measured 10% THD): 121 dB
switchable X-Over frequencies: 70Hz/100Hz/140Hz
Component Sub: DND12S400
Connector model Speakon: 1 x NL4 MPR for Sub 112 Extension
Dimensions (WxHxD) mm: 445 x 380 x 445
Net weight: 22,5 kg
Enclosure material: Birch plywood
Finish: 2-Comp. Paint
Grille, Steel: Powder coated
Front b/w: Acoustic Foam
Handles: 2
PowerSub 312
Color: Black
Cabinet: Powered 3-Channel Subwoofer
Lo Amplifier Power RMS: 800 W / 4 Ohms
Mid-High Amplifier Power RMS: 2 x 250 W / 4 Ohms
SPL 2,83V/1m (1W/8 ohms): 92 dB
Max. SPL 1m (calc. with peak power or measured 10% THD): 121 dB
switchable X-Over frequencies: 70Hz/100Hz/140Hz
Component Sub: DND12S400
Connector model: Speakon 1 x NL4 MPR for Sub 112 Extension
Dimensions (WxHxD) mm: 445 x 380 x 445
Net weight: 22,5 kg
Enclosure material: Birch plywood
Finish: 2-Comp. Paint
Grille: Steel Powder coated
Front: b/w Acoustic Foam
Handles: 2
