Frequency Response (-3dB): 70 - 20000 Hz
-
Frequency Response (-10dB): 55 - 20000 Hz
-
Recommended High-Pass Frequency: 60 Hz
-
Sensitivity 1W/1m: 99 dB
-
Max. SPL / 1m (calc): 132 dB
-
Coverage (nominal -6dB) H°: 90 °
-
Coverage (nominal -6dB) V°: 50 °
-
Rotatable Horn: No
-
System Power Handling (continuous/program/peak): 500/1000/2000 Watts
-
LF Transducer: SMX2121
-
HF Transducer: DH3
-
Crossover Frequency: 1600 Hz
-
Nominal Impedance (Passive): 8 Ohms
-
Minimum Impedance: 6.4 Ohms
-
Enclosure Material: Plywood and MDF with EVCOAT
-
Color: Black
-
Flying: No
-
Input Connections: Parallel Neutrik® NL4
-
Internal Crossover: Yes
-
Speaker Type: Fullrange
-
Weight Net: 19.8 kg
-
Dimensions (HxWxD): 440 x 364 x 573 mm
