Optimal Audio ZONE 8P

Audio kontroler, 8 zona sa DSP-om, integrisanim pojačalom i Web aplikacijom

Dostupnost proizvoda: Ima na lageru

Download:

Zone8P-Datasheet

Pozovite za cenu

Optimal Audio

Specifikacije proizvoda:

Opis proizvoda:

Features

  • Full suite of audio controls for up to 8 zones
  • Fully flexible signal routing
  • Eight channels of 100W integrated amplification at 4Ω or 8Ω
  • Bridge channels for 200W @ 8Ω for 70v applications
  • WebApp interface for easy system configuration and everyday control
  • 2 mic, 4 stereo line and 2 HDMI inputs
  • Fully programmable presets and timed events
  • Very competitive pricing


Zone 8P is a zonal audio controller with DSP providing everything required in a single compact unit to become the beating heart of an efficient, high-quality multi-zoned commercial sound system.

It has integrated amplification making installation straightforward and cost-effective and allows the user to independently allocate sources across eight configurable zones, such as a lobby, bar or restaurant. Each  zone can be configured to do precisely what is required using the intuitive WebApp including EQs, speaker presets, structured time of day routines and so much more.

Zone 8P features 4 line and 2 mic inputs plus 2 HDMI inputs for TV and video sound.

The integrated eight-channel amplifier in Zone 8P provide 100 watts per channel and eliminate the need for separate amplifiers for most small to medium applications.

Zone 8P has been designed to work seamlessly with other products in the Optimal Audio range and when coupled with our ZonePad series provides a simple, intuitive and cost-effective audio system with superb sound quality.


Specifications

TYPE

8 zone audio processor with DSP, amplification and loudspeaker presets

MIC INPUTS

2 with 48V phantom power, +12dB to +55dB gain

MIC INPUT PROCESSING

Fixed hi-pass filter @160Hz; sweepable mid-band 200Hz-5kHz, +/-12dB; HF shelf @12kHz

LINE INPUTS

4 stereo with +26dB gain trim. SPDIF option on input 1

HDMI INPUTS

2

LINE OUTPUTS

8

ZONEPAD SOCKETS

8

AMPLIFIER CHANNELS

8

AMPLIFIER POWER

100W at 4Ω or 8Ω

AMPLIFIER POWER (BRIDGED)

200W @ 8Ω

PAGING INPUTS (CAT 5)

2

LAN ETHERNET100Mbps

Yes

ALARM OVERRIDE

Yes

DIMENSIONS

(W) 480mm x (H) 88mm x (D) 400mm
(W) 18.90” x (H) 3.46” x (D) 15.75”

WEIGHT

10.3kg (22.7lbs
