Available Coverage Patterns (Nominal -6 dB) HxV |
60x40, 60x60, 90x40, 90x60, 90x90, 120x60 ° |
|
Environmental Specs |
Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55 |
|
Input Connections |
Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover |
|
Internal Passive Crossover Frequency |
1300 Hz |
|
Frequency Response (-3 dB) |
57 - 18000 Hz |
|
Frequency Response (-10 dB) |
49 - 21000 Hz |
|
Recommended High-Pass Frequency |
65 Hz |
|
Sensitivity 1 W/1 m |
97 dB |
|
Max. SPL/1m (calc) |
131 dB |
|
System Power Handling (Continuous/Program/Peak) |
600, 1200, 2400 Watts |
|
LF Transducer |
DVX3121A 12-inch (305 mm) woofer |
|
HF Transducer |
DH7N 3-inch (76 mm) diaphragm compression driver |
|
Nominal Impedance (Passive) |
8 Ω |
|
Minimum Impedance |
6 Ω |
|
Enclosure Material |
13-ply weather-resistant birch |
|
Grill |
Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind |
|
Suspension |
(22) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included) |
