MAx MINI 4 je audio mikser sa 2 mono MIC/LINE kanala i 1 stereo kanal. Njegovi MIC/LINE ulazni kanali uključuju fantomsko napajanje za kondenzatorske mikrofone. Poseduje plejer audio datoteka preko USB/Bluetooth porta, ugrađene efekte, 2 kontrole tona po kanalu, 7-pojasni stereo grafički ekvilajzer na glavnom izlazu i izlazu za slušalice.
2 Mono + 2 stereo inputs mixer with USB/BT
MAXMINI 4 is an audio mixer with 2 mono MIC/LINE channels and 1 stereo channel. Its MIC/LINE input channels incorporate phantom power for condenser microphones. It features an audio file player via USB/Bluetooth port, built-in effects, 2 tone controls per channel, 7-band stereo graphic equalizer on the master and headphone output.
Features
2 mono inputs + 2 stereo inputs.
Phantom power +48 V.
USB/Bluetooth interface.
7-band graphic equalizer and echo effect.
Mono Ch 2 Mic/Line
Stereo Ch 1 Line
Player USB and Bluetooth
Recorder USB
Effects Echo
Phantom Power +48 V
Connectivity USB and Bluetooth
Equalization HI: 10 kHz ± 15 dB; LOW: 100 Hz ± 15 dB
Phones Output Yes
Input Impedance Mic: 3 KOhm; Line: 10 KOhm
Hum and noise -128 dBu (Rs:150 Ohm¦, GAIN knob: max)
THD 0.01% @ +8 dBu, 1kHz, 80 kHz
Power supply AC 100 -240 V 50/60 Hz / DC 15V (External power supply included)
Dimensions 205 x 55 x 190 mm (W x H x D)
Weight 1 Kg
