Chassis Size |
381 mm (15") |
|
Color |
Black |
|
Environmental Specs |
IEC 529 IP24, MIL STD 810 |
|
Input Connections |
2 Neutrik® NL8 |
|
Peak SPL @ 10m |
124 dB 4 Box Array @ 10 Meters |
|
Frequency Response (-3 dB) |
40 - 400 Hz |
|
Frequency Response (-10 dB) |
30 - 400 Hz |
|
Sensitivity 1 W/1 m |
102 dB Single Box @ 1 Meter |
|
Max. SPL/1m (calc) |
138 dB Single Box @ 1 Meter |
|
Coverage (Nominal -6 dB) H |
300 ° |
|
System Power Handling (Continuous/Program/Peak) |
1000 Watts |
|
LF Transducer |
2 x 15-in DVX3150A |
|
LF Power Handling |
1000 W continuous, 4000 W peak Watts 60-100 Hz |
|
LF Nominal Impedance |
4 Ω |
|
Enclosure Material |
EVCoat®-coated birch plywood |
|
Flying |
Yes |
|
Outdoor |
No |
|
Grill |
Powder-coated steel |
|
Height |
546 mm (21.5") |
|
Width |
927 mm (36.5") |
|
Depth |
572 mm (22.52") |
|
Weight Net |
56.3 kg (124.12 lbs) |
