Color |
Black and White |
|
Environmental Specs |
IEC 529 IP24, MIL STD 810 |
|
Peak SPL @ 10m |
130 dB 4 Box Array @ 10 Meters |
|
Sensitivity (LF/MF/HF) |
95/101/111 dB Single Box @ 1 Meter |
|
Frequency Response (-3 dB) |
65 - 16,000 Hz |
|
Frequency Response (-10 dB) |
54 - 17,000 Hz |
|
Max. SPL/1m (calc) |
128/132/139 dB Single Box @ 1 Meter |
|
Coverage (Nominal -6 dB) H |
120 ° |
|
LF Transducer |
1 x 12-in DVX3121A |
|
LF Power Handling |
500 W continuous, 2000 W peak Watts 100-500 Hz |
|
HF Power Handling |
150 W continuous, 600 W peak Watts 1600-8000 Hz |
|
LF Nominal Impedance |
8 Ω |
|
MF Power Handling |
300 W continuous, 1200 W peak Watts 500-2000 Hz |
|
MF Transducer |
2 x 6.5-in DVN 2065 |
|
MF Nominal Impedance |
8 Ω |
|
HF Transducer |
2 x 3-in ND6-16 |
|
HF Nominal Impedance |
8 Ω |
|
Connector Type |
2 Neutrik® NL8 |
|
Enclosure Material |
EVCoat®-coated birch plywood |
|
Grill |
Powder-coated steel |
|
Height |
362 mm (14.25") |
|
Width |
927 mm (36.5") |
|
Depth |
572 mm (22.52") |
|
Weight Net |
48.1 kg (106.04 lbs) |
